D-Link DSL-2640B Quick Install Guide

2D-Link DSL-2640B Quick Install Guide
• ADSL2/2+ 4-Port Wireless Router
• 12VDC, 1A DC CEC-compliant switching power adapter
• RJ-11 telephone cable
• RJ-45 Ethernet cable
• Quick Install Guide
• CD-ROM (User Manual + QIG)
General Information
The D-Link DSL-2640B is an ADSL2+ wireless router, that combines
a DSL router and wireless solution in a single device. The DSL-2640B
also has four addional 10/100Mbps Ethernet ports to connect
non-wireless computers. This user manual provides you with a simple
and easy-to-understand format to install and configure your router.
Package Contents
Note: Using a power supply with a different voltage rating than the
one included with the DSL-2640B will cause damage and void the
warranty for this product.
If any of the above items are missing, please contact your reseller.

D-Link DSL-2640B Specifications

Power

input voltage	100V-240V
input current	0.6A
input frequency	50 Hz -60 Hz
output voltage	12V
output current	1A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps

Wireless Transfer Rates

IEEE 802.11b transfer rates	11, 5.5, 2, and 1 Mbps
IEEE 802.11g transfer rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Media Interface

ADSL interface	RJ-11 connector
LAN interface	four RJ-45 ports
Ethernet connection type	10/100BASE-T
