D-Link DWA-130 User Manual

20D-Link DWA-130 User Manual
Section 3 - Configuration
If you want to connect using the PBC method, refer to page 14. To
use the PIN method, select PIN (Personal Identification Number)
and click Next.
Click Next
Make sure your access point or wireless router is close by. Write
down the number on the screen. Enter this number in your access
point or wireless router. Please refer to the manufacture’s manual
for instructions.
Once you click Next, you will have 2 minutes to enter this number
in your access point or wireless router.
Click Next
Personal Identification Number (PIN)

D-Link DWA-130 Specifications

Operating Environment

operating temperature	32˚ to 104˚F (0˚ to 40˚C)
operating humidity	10 ~ 90% Non-condensing
frequency range	2.4GHz to 2.462GHz

Weight and Dimensions

item dimensions (WxDxH)	1.1” x 3.4” x 0.5”
packaging dimensions (WxDxH)	6.6” x 9.5” x 1.5”
item weight	0.1 lbs
