D-Link DWR-978 Quick Installation Guide

DWR-978
18
ITALIANO
• Computer o dispositivo mobile con adattatore wireless 802.11ac/n/g
• Internet Explorer
®
9, Firefox
®
12, Chrome™ 20 o Safari 5
• Scheda SIM mini
• Abbonamento con un provider di servizi Internet mobile
REQUISITI DI SISTEMA
CONFIGURAZIONE ANTENNA
Fase 1:
Collegare le due antenne ai connettori SMA sul retro di DWR-978.
Ruotare in senso orario per ssare le antenne.
Fase 2:
Disporre le antenne in modo che siano rivolte verso l'alto e in una
congurazione per ricevere segnali ottimali.
Antenne
esterne
Router
DWR-978 5G AC2600 Wi-Fi Router necessita del corretto funzionamento di due antenne esterne. le
antenne incluse sono interscambiabili.
Antenne
esterne
Router

D-Link DWR-978 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
3G/4G USB modem compatibility	-
4G standard	LTE-FDD
3G standards	WCDMA
SIM card type	NanoSIM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2600 Mbit/s
WLAN data transfer rate (first band)	800 Mbit/s
WLAN data transfer rate (second band)	1733 Mbit/s
Product type	Tabletop router
Product color	White
LED indicators	LTE, Power, WAN, WLAN
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11k, IEEE 802.11r, IEEE 802.11v
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Security algorithms	WPA, WPA2, WPA3
Antennas quantity	8
Output current	1 A
Output voltage	12 V
Power source type	AC
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Mobile operating systems supported	Android, iOS
Number of products included	1 pc(s)
Sustainability certificates	CE, RoHS

Weight and Dimensions

Depth	245 mm
Width	234.5 mm
Height	55.25 mm
Weight	920 g
