D-Link E15 Quick Installation Guide

4
ENGLISH
PLACEMENT
One amber bar indicates a weak signal. Move your extender closer to
your router to improve signal quality. Make sure that your extender is
placed in an open environment.
Place the extender in range of your router. Check the LED indicator
on your extender to ensure a proper connection. White bars indicate
a strong signal.
< 1 m
< 1 m
< 1 m
< 1 m
Note: Please refer to the User Manual for device specific LED behaviour.

D-Link E15 Specifications

General

Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	WPA, WPA2, WPA3, WPS
Networking standards	IEEE 802.11ax
Wi-Fi data rate (max)	1200 Mbit/s
Type	Network transmitter
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum transfer distance	- m
Mobile operating systems supported	Android, iOS
Antenna type	External
Certification	FCC, IC, UL
Mounting type	Wall
Product color	White
Antennas quantity	2
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	CE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	11 W
Ethernet LAN (RJ-45) ports	1
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	63.5 mm
Width	105 mm
Height	50 mm
Weight	161 g
