LOC PART-CODE PART-NAME PART-DESC
00070 9970800018 CABLE SIGNAL AS 15P+2C/DDC=1.5M(IVY)
00080 W1173D831- CORD POWER SP30+IS14(I)
00090 9970K00016 CORE FERRITE OP-18(B)
00100 9979500015 RECEPTACLE 03GEEG3B/FILTER EMI
10000 9979800466 PCB MAIN CMC-901D T=1.6*330*246
10000 9979800467 PCB VIDEO CMC-901D T=1.6*246*120
10000 9979800468 PCB CRT CMC-901D T=1.6*68*68
10000 9979800470 PCB CONTROL CMC-901D T=1.6*193*35
B001 5PB13857— COIL BEAD BI3857(AXIAL)
B002 5PB13857— COIL BEAD BI3857(AXIAL)
B004 5PB13857— COIL BEAD BI3857(AXIAL)
B191 5PB13857— COIL BEAD BI3857(AXIAL)
B301 5PB13857— COIL BEAD BI3857(AXIAL)
B501 5PB13857— COIL BEAD BI3857(AXIAL)
B801 5PB13857— COIL BEAD BI3857(AXIAL)
B802 5PB13857— COIL BEAD BI3857(AXIAL)
B803 5PB13857— COIL BEAD BI3857(AXIAL)
B804 5PB13857— COIL BEAD BI3857(AXIAL)
B805 5PB13857— COIL BEAD BI3857(AXIAL)
B807 5PB13857— COIL BEAD BI3857(AXIAL)
B808 5PB13857— COIL BEAD BI3857(AXIAL)
B812 5PB13857— COIL BEAD BI3857(AXIAL)
B813 5PB13857— COIL BEAD BI3857(AXIAL)
B833 5PB13857— COIL BEAD BI3857(AXIAL)
B863 5PB13857— COIL BEAD BI3857(AXIAL)
B991 5PB13857— COIL BEAD BI3857(AXIAL)
BNC1 9976300032 CONN BNC CONN BNC
BNC2 9976300032 CONN BNC CONN BNC
BNC3 9976300032 CONN BNC CONN BNC
BNC4 9976300032 CONN BNC CONN BNC
BNC5 9976300032 CONN BNC CONN BNC
C001 CL1UC3474M C LINE ACROSS
0.47MF 1J(UCVSNDF/SV)+Q/O
C002 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C003 CH1FDF472M C CERA AC HIKB AC400V 4700PF M
C004 CH1FDF472M C CERA AC HIKB AC400V 4700PF M
C005 CH1FDF472M C CERA AC HIKB AC400V 4700PF M
46
ELECTRICAL PARTS LIST
The components identified by mark have special characteristics important for safety and x-ray radiation.
These should be replaced only with the types specified in the parts list.
LOC PART-CODE PART-NAME PART-DESC
