57
¡ DSA-151L/DSA-181L/DSB-181L
No PART NAME SPEC Q’TY PART CODE REMARK
1 CONTROL BOX ASS’Y
DSA-151L/DSA-181L 1 3100058320
DSB-181L 1 3100058210
2 BOX CONTROL-2 ABS (VERSION2) 1 3100506900
3 PCB TRANS ASS’Y
DWA-5423 1 5EPK633110
DWA-220V 1 5EPV633110
4 SCREW TAPPING T2S TRS 4X12 MFZN 3 7122401211
5 CAPACITOR IDM EAF-45125 (1.2µF/450V) 1 3106900210
6 SCREW TAPPING T2S TRS 4X24 MFZN 1 7141402411
7 TERMINAL BLOCK SN-DBW-4P 1 3108912320
8 SCREW TAPPING T2S TRS 3X16 MFZN 2 7111301611
9 HARNESS POWER UL1015 #16/18 1 3102704010
10 HARNESS EARTH UL1015 #18 1 3102797910
11 HARNESS COMP SIGNAL UL1015 #18 1 3102704410
12 POWER CORDWS-93 (250V 10/16A) 1 31013A24B1
13 CABLE CORD DA-5N 1 3101200300
14 CONTROL PCB ASS’Y
DSA-151L/DSA-181L 1 3104300120
DSB-181L (COOL/50Hz) 1 3104300110
15 HARNESS CONNECTING UL 1007 #26 1 3102704900
16 POWER PCB ASS’Y DSA-151L/DSA-181L/DSB-181L 1 3104300210
17 LED PCB ASS’Y 15/18K 1 3104300300
18 SWITCH PCB ASS’Y 15/18K 1 3104300400
19 SENSOR ID ASS’Y PEM-KD43C-D1 1 3104896000
20 HARNESS LED PCB UL 1007 #26 1 3102704510
21 HARNESS SWITCH PCB UL 1007 #26 1 3102707000
22 KNOB SWITCH ABS 1 3103400200
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
To Next Page
