Daewoo DSC-1245FL User Manual

Air Conditioner Service Manual
PARTS LIST
Indoor unit:
Model: DSA-1285FL DSA-1885FL DSA-2485FL
No. Part No. Part Name Q’ty Remark
1
Installation Plate
1
2
Base
1
3
Vertical Vane Assembly
2
4
Cross Fan
1
5
Bearing Mount
1
6
Evaporator
1
7
Face Frame
1
8
Screw Cover
2
9
Air Filter
2
10
Display PCB Box
1
11
Display PCB
1
12
Front Panel
1
13
Vane
1
14
Power Supply Cord
1
15
Cable Clamp
1
16
Main PCB
1
17
Electrical Box
1
18
Transformer
1
19
Indoor Sensor Assembly
1
20
Sensor Holder
1
21
Indoor Motor
1
22
Indoor Motor Cover
1
23
Drainage Hose
1
24
Vane Motor
1
25
In And Out Pipe Fixer
1
26
Remote Controller
1
Not shown in Explosion view
27
Remote Controller Supporter
1
28
Indoor Carton
1
29
Left Foam
1
30
Right Foam
1
18
