10. REFRIGERANT CYCLE
8
1
2
3
4
5
6
Cooling Ai
r
Heated Air
Flow 2
Refrigerant flowing
direction
7
Flow 1
1：Compressor 2：Condenser 3：Axial flow fan 4：Motor 5：Centrifugal fan 6：
Vapor liquid separator 7：Capillary 8：Evaporator
- 17 -
