6.ESPECIFICACIONES DE PARTES ELECTRÓNICAS

1 VALVE INLET (2-Way) 110-130/50-60 - ◎ 3615415800 100-130 2WAY PP/BRACKET DR12AS

2 VALVE INLET (3-Way) 110-130/50-60 ◎ - 3615415900 100-130 3WAY PP/BRACKET DR12AS

3 SENSOR PRESSURE 5V ◎◎3614825200

5V DRUM, DL-DW01 DL-DW01

5V DRUM, DN-DD01 DN-DD01

Taiwan:

4 CORD POWER AS 3611339800 ◎◎3611339810 VCTFK 2C 15A 125V LP-70

5 UNIT BUBBLE PUMP 100-130/50-60 ◎◎36189L4G00 100-130 DBK-115DA RP-CUSH DBK-115DA

6 HARNESS AS

DWD-E1211RT ◎ - 3612793210 DRUM DRY-WASH-PO-NON HOT -

DWD-E1211WT - ◎ 3612793310 DRUM WASH ONLY-PO-NON-HOT -

7 HARNSS EARTH 110 A11 ◎◎3612793400 GN/YW AWG18 FERRITE -

8 FUSE TEMPERATURE 15A 250V ◎ - 361A800100 128℃DF 128s 15A 250V DF128s

9 SWITCH DOOR LOCK 100-130/50-60 ◎◎3619046410 DF’s 125V 16A PTC-SOLEN0ID DF

10 HEATER WASH 110/50-60 ◎◎3612801100 110V 1KW 12.1Ω4.3W/SQ SUS 1R1A03305 144℃ IR1A033005

11 HEATER DRY 110/50-60 ◎ - 3612801300

110V 1.2KW 23.0Ω6.1W/SQ INCOLOY800 1R1A034001

IR1A034005

12 SWITCH THERMOSTAT 100-250V ◎ 3619046500 ON 120℃OFF 150℃230V 15A VDE NT-103NA

UNIT MOTOR BLDC 36189L4000 3254D02000, 3114D02000, 310V, 250W 3254D02000,

13 UNIT STATOR BLDC A11 ◎◎36189L4800 Φ265X28H, 36SLOT, 25NESOR, 3254D02000 3114D02000

UNIT ROTOR BLDC 36189L4900 MAGNET24, SERRATION, 3114D02000

14 THERMISTOR WASH A11 ◎◎361AAAAB00 R25=11, 981㏀, R80=1, 704㏀

CWT-DEW-1C03-0

15 THERMISTOR Dry ◎ - 361AAAAC00 R40=26, 065㏀, R90=4, 4278㏀

CWT-DEW-1C02-0

16 UNIT FAN MOTOR Dry ◎ - 36189L3Z00 ISM-77806DWWA 24V CW 8P 14W

ISM-77806DWWA

17 FAN AS Dry ◎ 3611885700 Φ133x45L IMPELLER -

18 DRAIN MOTOR 100-130/50-60 ◎◎36196TAK00 SV-HJ7T20D 100-110V ST23(56.5) SV-HJ7T20D

19 DAMPER FRICTION 11kg A11 ◎◎361A700100 70N AKS ST=170-245 DL=197.5 -

20 DAMPER PIN 11kg A11 ◎◎361A700200 AKS D=14.5 -

NO PART NAME Rating (V/Hz)

Model

WASH+DRY WASH

PART CODE TYPEBOM DESCRIPTION
