PARTS DIAGRAM
Parts List
NO. PARTS NAME PARTS CODE SPECIFICATION REMARK
A01 SWITCH SAFETY 3619044130 030A7 #187, B:9MM
A02 SENSOR PRESSURE 3614802300 DC 5V, 2PIN
A03 PANEL REAR 3614238010 ABS
A04 RADICAL GENERATOR 36100E2C40 AC 220V/50,60HZ
36100E2C50 AC 100-110V/50,60HZ
36100E2C60 AC 220-240V/50HZ
36100E2C70 AC 120-127V/60HZ
A05 VALVE INLET AS 3615408900 AC 220V/60HZ, C SINGLE VALVE
3615408910 AC 100V/50,60HZ, C
3615408920 AC 110-130V/60HZ,C
3615408930 AC 220-240V/50HZ, C
3615407800 AC 220V/60HZ, C&H DUAL VALVE
3615407810 AC 100V/50,60HZ, C&H
3615407820 AC 110-130V/60HZ, C&H
3615407830 AC 220-240V/50HZ, C&H
A06 UNIT CAPACITOR 3618955300 16.5µF, 400VAC, 220V 260W
3618912500 65µF, 200VAC, 110V
3618911300 12.5µF, 400VAC, 230-240V 200W
3618911400 13.5µF, 400VAC, 220V
3618911800 41.6µF, 230VAC, 127V
3618912400 54µF, 200VAC, 110V
A07 CASE DETERGENT 3611132510 ABS
A08 PLATE T 3614522610 PP
A09 NOZZLE DETERGENT 3618102500 PP
A10 SCREW TAPPING 3610909900 T1S TRS 5*30 MFZN
A11 PANEL SIDE L 3614238110 ABS
A12 PANEL SIDE R 3614238210 ABS
A13 PANEL F 3614238310 ABS
A14 DECORATOR PANEL F 3611620900 PC FILM 0.188T
A15 PCB AS PRPSSW1X00 101WA(L3, V2F) 200W, 220V/60Hz
PRPSSW1X02 131WA(L3, V2F) 260W, 220V/60Hz
PRPSSW1X03 200WSP(L5, V1F) 127V/60Hz, PUMP
PRPSSW1X04 200WTC(L6, V1F) 110V/60Hz
PRPSSW1X05 260WTC(L6, V1F) 110V/60Hz
PRPSSW1X05 200WNP(V2F) 220V/50Hz, PUMP
A16 DOOR B 3611799110 ABS
A17 SPRING DOOR 3615111210 850M, 98'S, 100'S D=2.0
A18 HANDLE DOOR AS 3612904940 ABS, 101WA
37
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
