19
OPERATION AND FUNCTIONS
NO
CONTROL
FUNCTION
CONTROL
OBJECTS
CONTENTS REMARK
¨ç Proceeding time: 4min
¨è Control Object: Comp Off,
FAN Off,Heater Off
¨çProceeding time: 4min
¨è Control Object: Comp On,
FAN Off, Heater Off
4) Output Control and Limit Time of each Defrosting mode
2.Forced Defrosting
1) Start: Defrosting starts by pressing Temp.control s/w five times in a
row when door is open.
2) End : No function
3) Process: using Heater
4) Defrosting mode and procedure:
same as Normal Defrosting( Skip pre-cool mode )
5) Heater is On during initial 30 seconds without conserning D-sensor
Temp.
5 Initial
Defrosting
COMP
F-FAN HTR
1. If D-sensor temp. *3.5°C in the initial power input, normal defrosting
mode begins without concerning Comp run-time ( include Pre-cool
mode )
2. Defrosting begins after doing Comp restart prevention function with
dealy for six min. in initial defrosting mode.
3. Comp will be On imme
diately if D-sensor temp. ]3.5°C in initial power input.
( No dealy for six min. )
6 Prevention of
Comp
COMP
F-FAN
1. In order to protect Comp after Comp ioff, it won’t re-start for six min.
though R-sensor becomes On.
PAUSE
Fan Delay
Normal Run
To Next Page
