6-2.TOTAL PARTS LIST
*Caution : In this Service Manual, some parts can be changed for improving,their performance without notice in the parts list. So, if
you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center(http://svc.dwe.co.kr).
NO PART CODE PART NAME PART DESCRIPTION QUANTITY REMARK
3010074800 ASSY CAB URT FR-520NT 1
3010074900 ASSY CAB URT FR-550NT 1
2 3012905400 HINGE *T SCP1, T2.3 1
3 3016001240 SPECIAL BOLT *T 6×22 SWCH22A(YL) 5
4 3011429000 COVER *T HI PP 1
5 3010511700 BOX M/PCB PP 1
6 PCB MAIN AS RT30 1
8 3011425300 COVER MAIN PCB BOX PP 1
9 7112401611 SCREW TAPPING T1 TRS 4X16 MFZN 2
10 3012905802 HINGE *M AS PO T3.2 1
11 3011424700 COVER *M HINGE ABS 1
12 3016001220 SPECIAL BOLT *M 6X20 SWCH22A(WH) 3
13 3012102901 FOOT *F *L AS 1
14 3012103001 FOOT *F *R AS 1
15 3016000700 SPECIAL SCREW M6X15 2
16 3012101501 FOOT ADJ *R AS 1
17 3012102501 FOOT ADJ *L AS 1
18 3012906400 HINGE *U AS 1
19 3016005300 SPECIAL WASHER S10C T1.5 1
20 3016001240 SPECIAL BOLT T/U 6X22SWCH22A(YL) 3
21 3011470100 COVER CABINET BRAKET PP 1
22 7112401611 SCREW TAPPING T1 TRS 4X16 MFZN 2
23 3010101340 ABSORBER SUCTION PIPE NR 3
24 CORD POWER AS 1
25 7112401211 SCREW TAPPING T1 TRS 4X12 MFZN 1
26 7001400865 SCREW MACHINE PAN 4X8 BSNI 1
27 3013202700 HOSE DRAIN B PP 1
28 7112401211 SCREW TAPPING T1 TRS 4X12 MFZN 6
29 3012401410 GRILLE SBHGI T0.4 1
30 7112401211 SCREW TAPPING T1 TRS 4X12 MFZN 2
31 3014423900 PIPE WICON AS FRB-48/52/5640NT 1
32 3010102100 ABSORBER C MOTOR NR 1
33 3012004400 FIXTURE C MOTOR SUC 1
34 MOTOR C 1
35 3011802200 FAN 1
36 3011200500 CLAMP FAN SUS304 1
37 DRYER AS FRB-4460NT/4760NT 1
38 3011118000 CASE VAPORI 1
39 3010314910 BASE COMPRESSOR SBHGI T1.0 1
40 COMPRESSOR 1
41 3010101440 ABSORBER COMP AS 4
42 3016002500 SPECIAL WAHER SK-5 T0.8 4
43 SWITCH P-RELAY AS 1
44 3811400503 COVER RELAY V235 1
