10) LAMP ASSEMBLY
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/60 220~240 / 50 230 / 50
X 120V 15W 240V 15W
X 3013600070 3013600060
X 120V 25W 230~240V 25W
X 3013602020 3013602010
11) MAIN PCB ASSEMBLY
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/60 220~240 / 50 230 / 50
X Y202-SBS
X 30143B4011 30143B4021
12) FUSE (PCB)
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/60 220~240 / 50 230 / 50
RATED CURRENT
X 250V/3.15A
X 5F3GB3282R
13) THERMOSTAT FUSE
REFRIGERANT R134a
VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/60 220~240 / 50 230 / 50
x
77℃
x 30127201400
PART CODE
TYPE NAME
PART CODE
SPEC (W)
PART CODE
PART CODE
OPERATING TEMPERATURE
SPEC (W)
PART CODE
- 9 -
