2) Ice Cubes Maker & Ice Cubes Case
3) Drying Case & Meat Case
4) Front Cover
* Pull forward Ice case and lift up a little to remove then pull Ice cubes maker.
* Pull forward and lift up a little like Ice case.
- Fruit case, vegetable case and chilled case
in Refrigerator are the same way.
* At first remove the screw caps with a (-) driver.
* Unscrew three screws with a (+) dirver.
* Assembling order is the reverse of disassembling. In order to assemble,
match front cover to the cabinet groove before screwing.
- 44 -
