Dahua DH-IPC-HFW1120SP-0360B User Manual

Dahua HD Mini IR Waterproof Bullet Network Camera Quick Start Guide
1
1 Framework
1.1 Device External Cable
You can refer to the following figure for cable information. See Figure 1-1.
Figure 1-1 Cable
Please refer to the following sheet for detailed information.
SN
Port
Port name
Connector
Function description
1
LAN
Network port
Ethernet
port
Connect to standard Ethernet cable.
Note:
Some devices do not support PoE power supply.
2
DC 12V
Power input
port
-
Power port. Input DC 12V.
1.2 Framework and Dimension
The following figures are for reference only, which are used to know the device dimension,
please refer to the following figure according to the actual device.
Figure 1-2

Dahua DH-IPC-HFW1120SP-0360B Specifications

General

Brand	Dahua
Model	DH-IPC-HFW1120SP-0360B
Category	Security Camera
Language	English
