Specifications SiUS121827E
32 Part 2 Specifications
Model FDMQ24RVJU
Cooling Heating
Power Supply Phase 1 φ
Hz, V 60 Hz, 208 - 230 V
Rated Capacity 24 kBtu/h Class
Casing Color —
Dimensions (H × W × D) in. (mm) 9-5/8 × 39-3/8 × 31-1/2 (245 × 1,000 × 800)
Coil Type Cross Fin Coil
Rows × Stages × Fin per Inch 3 × 26 × 18
Face Area ft² (m²) 3-1/8 (0.288)
Fan Type Sirocco Fan
Motor Output W 230
Airflow Rate
H / M / L
cfm
(m
3
/min)
798 / 678 / 558
(22.6 / 19.2 / 15.8)
798 / 678 / 558
(22.6 / 19.2 / 15.8)
External Static
Pressure 1
inH
2
O 0.20 (0.60 - 0.20)
Pa 50 (150 - 50)
Sound Pressure Level dB(A) 40 40
Sound Power Level dB(A) 54 54
Air Filter 2 —
Weight (Mass) Lbs (kg) 82 (37)
Piping
Connection
Liquid in. (mm) φ 1/4 (φ 6.4) (Flare)
Gas in. (mm) φ 5/8 (φ 15.9) (Flare)
Drain in. (mm) I.D. φ 1 (φ 25) / O.D. φ 1-1/4 (φ 32) (Flare)
Remote
Controller
(Option)
Wired BRC1E73
Wireless
BRC082A43
Drawing No. 3D112997C
Notes 1. External static pressure is changeable in 11 stages by remote controller.
2. Air filter is not standard accessory, but please mount it in the duct system of the suction side.
Select its dust collection efficiency (gravity method) 50% or more.
Model FFQ09Q2VJU FFQ12Q2VJU
Cooling Heating Cooling Heating
Power Supply Phase 1 φ 1 φ
Hz, V 60 Hz, 208 - 230 V 60 Hz, 208 - 230 V
Rated Capacity 9 kBtu/h Class 12 kBtu/h Class
Decoration Panel
(1)
Model BYFQ60B3W1 BYFQ60B3W1
Color White White
Dimensions
(H × W × D)
in. (mm) 2-3/16 × 27-9/16 × 27-9/16 (55 × 700 × 700) 2-3/16 × 27-9/16 × 27-9/16 (55 × 700 × 700)
Weight (Mass) Lbs (kg) 6 (2.7) 6 (2.7)
Decoration Panel
(2)
Model BYFQ60C2W1W / BYFQ60C2W1S BYFQ60C2W1W / BYFQ60C2W1S
Color White / Silver White / Silver
Dimensions
(H × W × D)
in. (mm) 1-13/16 × 24-7/16 × 24-7/16 (46 × 620 × 620) 1-13/16 × 24-7/16 × 24-7/16 (46 × 620 × 620)
Weight (Mass) Lbs (kg) 6.2 (2.8) 6.2 (2.8)
Airflow Rates H
cfm
(m
3
/min)
378 (10.7) 399 (11.3) 406 (11.5) 427 (12.1)
M 339 (9.6) 357 (10.1) 353 (10.0) 371 (10.5)
L 268 (7.6) 282 (8.0) 268 (7.6) 282 (8.0)
Fan Type Turbo Fan Turbo Fan
Motor Output W — —
Speed Steps 3 Steps 3 Steps
Air Direction Control — —
Running Current (Rated) A 0.23 - 0.21 0.23 - 0.21 0.27 - 0.24 0.27 - 0.24
Power Consumption (Rated) W 23 23 27 27
Power Factor (Rated) % 48.1 - 47.6 48.1 - 47.6 48.1 - 48.9 48-1 - 48.9
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575)
Packaged Dimensions (H × W × D) in. (mm) 11 × 27 × 23-1/2 (280 × 686 × 597) 11 × 27 × 23-1/2 (280 × 686 × 597)
Weight (Mass) Lbs (kg) 36 (16) 36 (16)
Gross Weight (Gross Mass) Lbs (kg) 40 (18) 40 (18)
Sound Pressure
Level
H / M / L
dB(A) 38 / 35 / 29 38 / 35 / 29 39 / 36 / 30 39 / 36 / 30
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection Liquid in. (mm) φ 1/4 (φ 6.4) φ 1/4 (φ 6.4)
Gas in. (mm) φ 3/8 (φ 9.5) φ 3/8 (φ 9.5)
Drain in. (mm) VP20 (O.D. φ 1-1/32 (φ 26)) VP20 (O.D. φ 1-1/32 (φ 26))
Drawing No. 3D106061A 3D106062
Notes 1. SL: The quiet fan level of the airflow rate setting. 1. SL: The quiet fan level of the airflow rate setting.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
To Next Page
