• Air Handling Unit Connection • Heat pump
3
• Air Handling Unit Connection • ERQ-AV1
2 Specifications
2-1 Nominal Capacity and Nominal Input ERQ100A7V1B ERQ125A7V1B ERQ140A7V1B
Nominal Capacity Cooling capacity Standard kW 11.2 14.0 15.5
Heating capacity Standard kW 12.5 16.0 18.0
For combination
indoor units + outdoor
units
EER Nominal 3.99 3.42
COP Nominal 4.56 4.15 3.94
2-2 Technical Specifications ERQ100A7V1B ERQ125A7V1B ERQ140A7V1B
Capacity range HP 4 5 6
PED category Category 1
Casing Colour Daikin White
Material Painted galvanized steel plate
Dimensions Unit Height mm 1,345
Width mm 900
Depth mm 320
Packing Height mm 1,524
Width mm 980
Depth mm 420
Weight Unit kg 120
Packed Unit kg 130
Packing Material Carton + Wood + EPS
Weight kg 8
Heat Exchanger Dimensions Length mm 857
Nr of Rows 2
Fin Pitch mm 2
Nr of Passes 10
Face Area m² 1.131
Nr of Stages 60
Tube type Hi-XSS(8)
Fin Type Non-symmetric waffle louvre
Treatment Corrosion resistant
Fan Type Propeller
Discharge direction Horizontal
Quantity 2
Air Flow Rate
(nominal at 230V)
Cooling m³/min 106
Heating m³/min 102 105
Motor Quantity 2
Model Brushless DC motor
Motor Speed (nominal) Cooling rpm 850/815
Heating rpm 820/785 840/805
Fan Motor Output W 70
Drive Direct Drive
Compressor Quantity 1
Motor Model JT100G-VDL
Type Hermetically sealed scroll compressor
Speed rpm 6,480
Motor Output W 2.5 3.0 3.5
Starting Method Direct on line
Crankcase
Heater
W33
Operation Range Cooling Min °CDB -5
Max °CDB 46
Heating Min °CWB -20
Max °CWB 15.5
Sound Level (nominal) Cooling Sound Power dBA 66 67 69
Sound Pressure dBA 50 51 53
Heating Sound Pressure dBA 52 53 55
