• Split - Sky Air • FBA-A
3
• Indoor Unit • FBA-A
2 Specifications
Standard Accessories : Operation manual; Quantity : 1;
Standard Accessories : Installation manual; Quantity : 1;
Standard Accessories : Drain hose; Quantity : 1;
Standard Accessories : Metal clamp for drain hose; Quantity : 1;
Standard Accessories : Washer for hanger bracket; Quantity : 8;
Standard Accessories : Screws; Quantity : 40;
Standard Accessories : Insulation for fitting; Quantity : 2;
Standard Accessories : Sealing pads; Quantity : 5;
Standard Accessories : Clamps; Quantity : 4;
2-1 Technical Specifications FBA35A FBA50A FBA60A FBA71A FBA100A FBA125A FBA140A
Power input - 50Hz Cooling Nom. kW - 0.23
Heating Nom. kW - 0.23
Casing Colour Not painted (galvanised)
Material Galvanised steel plate
Dimensions Unit Height/Width/
Depth
mm 245/700/800 245/1,000/800 245/1,400/800
Packed unit Height/Width/
Depth
mm 890/900/295 890/1,200/295 890/1,600/295
Weight Unit kg 28.0 35.0 46.0
Packed unit kg 30.5 38.0 49.0
Heat exchanger Fin Type Cross fin coil (Multi slit fins with hydrophilic treatment and Ø5Hi-XA tubes)
Air filter Type Resin net
Fan Model QD16A1CM/QD16A1DM
Type Sirocco fan
Quantity 1 2 3
Air flow rate Cooling High m³/min 15.0 18.0 29.0 34.0
Mediu
m
m³/min 12.5 (1) 15.0 (1) 26.0 (1) 29.0 (1)
Low m³/min 10.5 12.5 23.0 23.5
Heating High m³/min 15.0 18.0 29.0 34.0
Mediu
m
m³/min 12.5 (1) 15.0 (1) 26.0 (1) 29.0 (1)
Low m³/min 10.5 12.5 23.0 23.5
External static
pressure
High Pa 150
Nom. Pa 30 40 50
Fan motor Quantity 1
Model Brushless DC motor
Speed Steps 3
Output Rated W 130 230 300
Sound power level Cooling dBA 60 56 58 62
Heating dBA -
Sound pressure level Cooling High/Medium/
Low
dBA 35.0/32.0 (1)/29.0 30.0/28.0 (1)/25.0 34.0/32.0
(1)/30.0
37.0/35.0 (1)/32.0
Heating High/Medium/
Low
dBA 37.0/34.0/29.0 31.0/28.0/25.0 36.0/33.0/
30.0
38.0/35.0/32.0
Control systems Infrared remote control BRC4C65 / BRC4C66
Wired remote control BRC1D528 / BRC1E53A7 / BRC1E53B7 / BRC1E53C7
Refrigerant Type R-32 / R-410A
Piping connections Sound absorbing insulation Butyl Rubber
Liquid Type/OD mm Flare connection/6,35 Flare connection/9,52
Gas Type/OD mm Flare
connection/
9.52
Flare connection/12.70 Flare connection/15.90
Drain VP20 (I.D. 20/O.D. 26)
Heat insulation Foamed polystyrene / Foamed polyethylene
Drain-up height mm 625

Daikin FBA-A Specifications

General

Brand	Daikin
Model	FBA-A
Category	Air Conditioner
Language	English
