Outlines & Dimensions
128
Outlines & Dimensions
Indoor Unit
Model: FWW02/03/04/05/06L
ETALP NOITALLATSNI ROF TINU EHT NI NGISED ETALP NOITALLATSNI LAUTCA NO DESAB ESAELP :ETON
FWW02/03/04L DIMENSION REFERENCE AT PAGE 1&2.
A
B
TOP VIEW
C
SIDE VIEW
H
I
B
THE MARK SHOWS PIPING DIRECTION
RAERRAER
RIGHT
LEFT
BOTTOM
BOTTOM
FRONT GRILLE FIXED SCREWS
(INSIDE)
LOUVER
SIGNAL RECEIVER
INDOOR UNIT
ON/OFF SWITCH
ROOM TEMPERATURE
THERMISTOR (INSIDE)
NAME PLATE
TERMINAL
BLOCK
WITH EARTH
TERMINAL
F
E
J
G
G
L
D
B
K
M
A
Gas pipe end
INSTALLATION PLATE FWW02/03/04L
Liquid pipe end
Through the wall
hole Ø 65mm
Drain hose position
F
 Recommended mounting plate retention spots
(5 spots in all)
Use tape measure as shown.
Position the end of a tape measure at

FRONT VIEW
Dimension
Model
A B C D E F G H I J K L M
FWW02/03/04L 800 288 206 166 184 42 46 55 56 154 182 263 52
Note: Dimension in mm
