4 English
• Are you sure that there are no obstacles near the air
outlet of the outdoor unit?
Such obstacles may result in declined performance and
increased running noises.
• If abnormal noises occur in use, stop the operation
of the air conditioner, consult your local dealer.
System relocation
• Consult your Daikin dealer about remodelling and
relocation.
Regarding drainage of drain piping
• Is the drain piping carried out properly to ensure
complete drainage?
If drain piping is not carried out properly, dirt and debris
may be accumulated in the drain piping and cause water
leakage. If it occurs, stop the air conditioner and consult
with your local dealer for assistance.
2. NAME OF PARTS
6
12
3
7
8
9
10
11
4 5
1
Air inlet
(Top of the unit)
2
Air lter
(Under the panel)
3 Air outlet
4
Vertical aps
(horizontal air outlet direction adjustment aps-
manual)
5
Horizontal aps
(vertical air outlet direction adjustment aps-auto)
6 Remote controller
7 Power supply wiring
8
Ground wire
Conducts electricity from the unit into the ground to
prevent electric shock.
9 Drain pipe
10 Refrigerant pipe transmission wiring
11
Name plate
(Indoor unit model name)
3. HOW TO ADJUST THE HORIZONTAL
FAN DIRECTION ANGLE
Hold the tabs on edge vertical aps (horizontal air outlet
direction adjustment aps) down slightly and adjust left and
right to match the room conditions or your preference.
Stop the horizontal aps at a position where you can hold
the tabs and adjust it left and right.
4. MAINTENANCE
(FOR SERVICE PERSONNEL)
WARNING
• Only a qualied person is allowed to perform
maintenance without daily maintenance.
• Before touching any of connection wirings, be sure
to turn off all power supply switches.
• Contact professional personnel about attachment of
accessories and be sure to use only accessories
specied by the manufacturer.
If a defect results from your own workmanship, it may
result in water leaks, electric shock or re.
• Do not use ammable materials (e.g., hairspray or
insecticide) near the product.
Do not clean the product with organic solvents such
as paint thinner.
The use of organic solvents may cause crack damage to
the product, electric shocks, or re.
• Consult your dealer regarding cleaning the inside of
the air conditioner.
Improper cleaning may cause breakage of plastic parts,
water leakage and other damage as well as electric
shocks.
CAUTION
• Before cleaning, be sure to stop unit operation, turn
the power circuit breaker off or remove the power
cord.
Otherwise, an electric shock and injury may result.
• Do not wash the air conditioner with water, as this
may result in electric shocks or re.
• Watch your steps at the time of air lter cleaning or
inspection.
High-place work is required, to which utmost attention
must be paid.
If the scaffold is unstable, you may fall or topple down,
thus causing injury.
NOTE
• Do not remove the air lter except when cleaning.
This may cause breakage.
01_EN_3P565390-1F.indd 4 25/04/2023 17:07:47
