Specifications
There are countless methods measuring speakers. However, none of them
actually represent how a speaker really sounds. Only by listening it is pos-
sible to determine whether one speaker sounds better than another. So
we only give you the specifications that are of real value to you. The DALI
Concept range has been designed to reproduce music as honestly as pos-
sible - and we know we have succeeded. Enjoy your new speakers!
Concept 1 Concept 2 Concept 6 Concept 8 Concept 10 Concept Center
Frequency Response [Hz] 62.5-22500 43-25000 41-25000 41-25000 35-25000 72-22500
Crossover Frequency [Hz] 3000 3000 3000 610 / 3500 600 / 3200 2500
Sensitivity (2,83V/1m.) [dB] 87 87 91 90 91 91
Nominal Impedance [Ohm] 8 8 8 6 6 8
Maximum SPL [dB] 106 108 110 112 114 109
Recommended Amp. Power (8 Ohm) [Watt] 25-100 40-120 30-150 40-160 50-200 25-120
High Frequency Driver 1 x 1" 1 x 1" 1 x 1" 1 x 1" 1 x 1" 1 x 1"
Midrange Driver - - - 1 x 5" 1 x 6½" -
Low Frequency Driver 1 x 5" 1 x 6½" 2 x 6½" 2 x 8" 2 x 10" 2 x 5"
Bass Reflex System Resonanse [Hz] 58.5 42.5 38.0 36.5 29.5 55.0
Dimensions (H x W x D) [cm]
Dimensions (H x W x D) [inch]
31x17x19
12.2x6.7x7.5
39x20x26
15.4x7.9x10.2
93x20x26
36.5x7.9x10.1
103x25x36
40.5x9.8x14.0
113x30x42
44.4x11.8x16.3
16x50x23
6.3x19.7x8.9
Weight [kg]/[lb.] 4 / 8.8 6.3 / 13.9 14.2 / 31 25 / 55 34 / 75 6.6 / 14.5
Wave
DALI cables for DALI speakers.
Concept SUB
Design Principle Active, built-in amplifier and crossover, sealed enclosure
Low Frequency Driver 1 x 12" air-dried pulp cone
Amplifier 160 Watt RMS
Inputs
Stereo line signal input RCA, input impedance 20 k
LFE Line signal input RCA, input impedance 35 k
Controls Volume level, lowpass crossover 50 - 170 Hz, phase ( 0 or 180˚)
Frequency Response 29-170 Hz
Maximum SPL 110 dB
Power Consumption 115/230 VAC, 50 - 60 Hz, 330 Watt
Dimensions (H x W x D) [cm]
Dimensions (H x W x D) [inch]
41x38x42
16.2x15.0x16.6
Weight [kg]/[lb.] 21.2/46.7
