5. Technical Data
CLX Home
Number of inverters 3
Inverter types DLX, ULX, TLX, TLX+, FLX
TLX Pro, TLX Pro+ and FLX Pro: when connected via RS-485 and
master functionality is not used.
Interfaces LAN (Ethernet 10/100 Mbit)
2 RJ-45 for RS-485 connection to the inverter network.
Cable requirement: minimum cat5e (shielded twisted pair cable is
required).
Local visualisation/operation App
Enclosure 2-part, fanless metal enclosure for rail mounting (IP20)
Weight 92 g net (without accessories and external AC mains adapter)
Humidity < 80% non-condensing
Ambient humidity Indoor/switch cabinet installation
Operating temperature 0 to 50 °C
Dimensions (without screws and
mounting plate)
26 mm, 110 mm, 80, mm (W, H, D)
Power 9 VDC
Standby Power Consumption 1.6 Watt
5. Technical Data
16 L00410618-03_02
5
