3.3Ageneraloverview:Whatdothesymbolsmean?
Symbol
Description
Outdoortemp.
Relativehumidityindoor
Roomtemp.
DHWtemp.
Temperature
Positionindicator
Scheduledmode
Comfortmode
Savingmode
Frostprotectionmode
Manualmode
Standby
Coolingmode
Activeoutputoverride
Optimizedstartorstoptime
Mode
Heating
Cooling
DHW
Commoncontrollersettings
Circuit
PumpON
PumpOFF
Actuatoropens
Actuatorcloses
Actuator,analoguecontrol
signal
Pumpspeed
Controlled
component
Symbol
Description
Alarm
Letter
Event
Monitoringtemperaturesensor
connection
Displayselector
Max.andmin.value
Trendinoutdoortemperature
Windspeedsensor
Sensornotconnectedornotused
Sensorconnectionshort-circuited
Fixedcomfortday(holiday)
Activeinfluence
Heatingactive
Coolingactive
Additionalsymbols,ECA30/31:
Symbol
Description
ECARemoteControlUnit
15
Connectionaddress(master:15,slaves:1-9)
Dayoff
Holiday
Relaxing(extendedcomfortperiod)
Goingout(extendedsavingperiod)
InECA30/31onlythesymbolsthatarerelevanttotheapplicationin
thecontrolleraredisplayed.
94|©Danfoss|2017.09
VI.GU.L2.02
OperatingGuideECLComfort210/296/310,applicationA275/A375
