List of literature
www.danfoss.com
Click: "Technical literature" in the left bar
Click: Refrigeration and Air Conditioning " > Technical literature"
Paste or write the no. in the box " Literature No."
Catalogue RK0YG
ETS valves, technical brochure DKRCC.PD.VD
Installation guide for data communication RC8AC
Installation considerations
Accidental damage, poor installation, or site conditions can give
rise to malfunctions of the control system, and ultimately lead to a
plant breakdown.
Every possible safeguard is incorporated into our products to
prevent this. However, an incorrect installation, for example, could
still present problems. Electronic controls are no substitute for
normal, good engineering practice.
Danfoss will not be responsible for any goods, or plant
components, damaged as a result of the above defects. It is the
installer‘s responsibility to check the installation thoroughly, and
to t the necessary safety devices.
Particular attention is drawn to the need for a "force closing" signal
to controllers in the event of compressor stoppage, and to the
requirement for suction line accumulators.
Your local Danfoss agent will be pleased to assist with further
advice, etc.
Your local Danfoss agent will be pleased to assist with further
advice, etc.
©Danfoss A/S (AC-MCI / sw), 2014-03 DKRCC.PS.RP0.A1.02/520H7142 2322 DKRCC.PS.RP0.A1.02/520H7142 ©Danfoss A/S (AC-MCI / sw), 2014-03
Manual Superheat controller type EKD 316Manual Superheat controller type EKD 316
EKD 316 – Parameter identication (modbus)
Explanations:
Parameter – The parameter name and abbreviation
PNU – The Parameter Number. Note: This is equivalent to the modbus register number (modbus address + 1)
R/W – R means read only, RW means it can be changed
Cong lock – If the parameter is cong locked it means that the value can only be changed when the main switch is o
Min – The minimum value of the parameter
Max – The maximum value of the parameter
Default – The default value of the parameter (factory setting)
Actual value – Values are read/written as 16 bit integer values without decimals. This is the default value as read via modbus
Scale – This shows the scaling factor of the value. *1 means that there is no scaling. *10 means that the read value is 10 times larger than
the actual value.
Parameter PNU R/W Cong lock Min Max Default Actual value Scale
Injection control (1)
n04 Kp factor 3003 R/W 0.5 20.0 2.0 20 *10
n05 Tn seconds 3004 R/W 30 600 120 120 *1
n06 Td seconds 3005 R/W 0 90 0 0 *1
n09 Max SH 3015 R/W 2.0 15.0 10.0 100 *10
n10 Min SH 3021 R/W 1.0 12.0 6.0 60 *10
n11 MOP 3013 R/W 0.0 200.0 20.0 200 *10
n15 Start time 3017 R/W 1 90 0 0 *1
n17 MinOdAtStart 3012 R/W 0 100 0 0 *1
n18 Stability 3014 R/W 0 10 5 5 *1
n19 Kp min. 3024 R/W 0.0 1.0 0.3 3 *10
n20 Kp T0 3025 R/W 0.0 10.0 0.4 4 *10
n21 SH mode 3026 R/W 1 2 1 1 *1
n22 SH close 3027 R/W 1.0 15.0 4.0 40 *10
n32 ETS OD% Max 3023 R/W 0 100 100 100 *1
n44 TnT0 sec. 3039 R/W 10 120 30 30 *1
o56 Reg. type 2076 R/W x 1 2 1 1 *1
Motor(2)
n37 Max steps 3032 R/W x 10 999 262 262 *1
n38 Max StepsSec 3033 R/W x 5 300 300 300 *1
n39 Start backlash 3034 R/W x 0 100 10 10 *1
n40 Backlash 3035 R/W x 0 100 23 23 *1
n03 Valve type 3002 R/W x 0 8 1 1 *1
Alarm settings (3)
A34 Battery low 10035 R/W 0 1 0 0 *1
Miscellaneous (11)
r05 Temp.unit 105 R/W 0 1 0 0 *1
r09 Adjust S2 113 R/W -10.0 10.0 0.0 0 x10
r10 Adjust S3 114 R/W -10.0 10.0 0.0 0 x10
o20 MinTransPres 2034 R/W -1.0 0.0 0.0 0 *10
o21 MaxTransPres 2033 R/W 1.0 200.0 12.0 120 *10
o30 Refrigerant 2551 R/W x 0 37 0 0 *1
o18 Manual ctrl. 2075 R/W 0 3 0 0 *1
o45 Manual OD% 2064 R/W 0 100 0 0 *1
Service (12)
o61 Appl.mode 2077 R/W x 1 2 2 2 *1
u10 DI1 status 2002 R 0 1 0 0 *1
u06 Analog input 2504 R 0.0 30.0 0.0 0.0 *10
--- AL/Light rel 2509 R 0 1 0 0 *1
--- Reset alarm 2046 R/W 0 1 0 0 *1
--- Rfg.Fac.A1 2548 R/W 8000 12000 10428 10428 *1
--- Rfg.Fac.A2 2549 R/W -4000 -1000 -2255 -2255 *1
--- Rfg.Fac.A3 2550 R/W 1000 3000 2557 2557 *1
Alarms (13)
--- Standby 20000 R 0 1 0 0 *1
--- EKC Error 20001 R 0 1 0 0 *1
--- S2 Error 20002 R 0 1 0 0 *1
--- S3 Error 20003 R 0 1 0 0 *1
--- P
e
inp.error 20004 R 0 1 0 0 *1
--- AI inp.error 20005 R 0 1 0 0 *1
--- No Rfg. Sel. 20006
R 0 1 0 0 *1
--- Battery low 20008 R 0 1 0 0 *1
Danfoss only (14)
o03 Unit addr. 2008 R/W x 1 240 240 240 *1
No text (15)
r12 Main switch 117 R/W 0 1 0 0 *1
u20 S2 temp. 2537 R -200.0 200.0 0.0 0.0 *10
u21 Superheat 2536 R 0.0 100.0 0.0 0.0 *10
u22 SuperheatRef 2535 R 0.0 100.0 0.0 0.0 *10
u24 Opening % 2542 R 0 100 0 0 *1
u25 EvapPress P
e
2543 R -200.0 200.0 0.0 0.0 *10
u26 EvapTemp T
e
2544 R -200.0 200.0 0.0 0.0 *10
u27 Temp. S3 2545 R -200.0 200.0 0.0 0.0 *10
--- EKC State 2007 R 0 100 0 0 *1
