The scaling (parameters 315 and 316) does not
influence the read-out. Min. and max. are determined
by the offset and gain adjustment of the AD-converter.
Pulse reference, parameter 532:
The value shown indicates any pulse reference in
Hz connected to one of the digital inputs.
External reference %, parameter 533:
The value stated gives, as a percentage, the sum of
external references (sum of analogue/bus/pulse).
Status word, parameter 534:
Indicates the status word transmitted via the serial
communication port in Hex code from the frequency
converter. See the Design Guide.
Brake power/2min., parameter 535:
Indicates the brake power transmitted to an external
brake resistor. The mean power is calculated on
an ongoing basis for the latest 120 sec.
Brake power/sec., parameter 536:
Indicates the given brake power transmitted
to an external brake resistor. Stated as an
instantaneous value.
Heat sink temperature, parameter 537:
States the given heat sink temperature of the
frequency converter. The cut-out limit is 90 ± 5°C,
while the unit cuts back in at 60 ± 5°C.
Alarm word, parameter 538:
States in Hex format whether there is an alarm
on the frequency converter.See section Warning
word 1, Extended status word and Alarm word
for further information.
VLT control word, parameter 539:
Gives the control word sent via the serial communication
port in Hex code to the frequency converter. See
the Design Guide for further information.
Warning word, 1, parameter 540:
States in Hex format whether there is a warning
on the frequency converter. See section Warning
word 1, Extended status word and Alarm word
for further information.
Extended status word Hex, parameter 541:
States in Hex format whether there is a warning
on the frequency converter.
See section Warningword1,Extendedstatusword
and Alarm word for further information.
Motor RPM, parameter 557:
The displayed value corresponds to the actual
motor RPM. In open loop or closed loop process
control, the motor RPM is estimated. In speed
closed loop modes, it is measured.
Motor RPM x scaling, parameter 558:
The displayed value corresponds to the actual
motor RPM multiplied by a factor (scaling)
set in parameter 008.
■ LCP procedure for entering text
After selecting Display Text in parameter 009 and 010,
select display line parameter (553 or 554) and press
the CHANGE DATA key. Enter text directly into the
selected line by using UP,DN&LEFT,RIGHTarrow
keys on the LCP. The UP and DN arrow keys scroll
through the available characters. The Left and Right
arrow keys move the cursor through the line of text.
To lock in the text, press the OK key when the line of text
is completed. The CANCEL key will cancel the text.
The available characters are:
ABCDEFGHIJKLMNOPQRSTUVWXYZ
ÆØÅÄÖÜÉÌÙè./-()0123456789’space’
’space’ is the default value of parameter 553 &
554. To erase a character that has been entered,
it must be replaced with ’space’.
553 Display text 1
(DISPLAY TEXT ARRAY 1)
Value:
Max. 20 characters
[XXXXXXXXXXXXXXXXXXXX]
Function:
Here, a text of max. 20 characters can be written
that will be shown in display line 1, provided LCP
display text [27] has been selected in parameter 010
Display line 1.1. Example of display text:
175ZA792.10
VLT NO.8
SETUP
1
CLEANING SYSTEM NO.2
AUTO REMOTE RUNNING
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
MG.51.A9.02 - VLT is a registered Danfoss trademark
156
