MCA 121 EtherNet/IP Add On Instruction
4
MIxxxxxx - VLT
®
is a registered Danfoss trademark



7. For 103/153 the associated additional process data (PCD) words need to be configured. To do this set the following
parameters via the Main Menu.

Parameter Description Setting
12-21 [0] Process Data Config Write [1680] Fieldbus CTW 1
12-21 [1] [1682] Fieldbus REF 1
12-22 [0] Process Data Config Read [1603] Status Word
12-22 [1] [1605] Main Actual Value [%]
12-22 [2] [1614] Motor Current
12-22 [3] [1614] Motor Current
12-22 [4] [1690] Alarm Word
12-22 [5] [1690] Alarm Word
12-22 [6] [1692] Warning Word
12-22 [7] [1692] Warning Word


