VLT
®
FCD Series
All about FCD
300
■ Factory settings
PNU # Parameter
description
Factory setting Changes
during
operation
4-setup Conv.
index
Data
type
302 Digital input, term. 18 Start Yes Yes 0 5
303 Digital input, term. 19 Reversing Yes Yes 0 5
304 Digital input, term. 27 Reset and coast inverse Yes Yes 0 5
305 Digital input, term. 29 Jog Yes Yes 0 5
307 Digital input, term. 33 No function Yes Yes 0 5
308 Term. 53, analogue input voltage Reference Yes Yes 0 5
309 Term. 53, min scaling 0.0 V Yes Yes -1 6
310 Term. 53, max scaling 10.0 V Yes Yes -1 6
314 Term. 60, analogue input current No function Yes Yes 0 5
315 Term. 60, min scaling 0.0 mA Yes Yes -4 6
316 Term. 60, max scaling 20.0 mA Yes Yes -4 6
317 Time out 10 sec. Yes Yes -1 5
318 Function after timeout No function Yes Yes 0 5
319 Term. 42, analogue output 0-I
MAX
=0-20mA Yes Yes 0 5
323 Relay output No function Yes Yes 0 5
327 Pulse Max. 33 5000 Hz Yes Yes 0 7
328 Pulse Max. 29 5000 Hz Yes Yes 0 7
341 Term. 46 digital output No function Yes Yes 0 5
342 Term. 46 Max. pulse output 5000 Hz Yes Yes 0 6
343 Precise stop function Normal ramp stop No Yes 0 5
344 Counter value 100000 pulses No Yes 0 7
349 Speed comp delay 10 ms Yes Yes -3 6
MG.04.B7.02 - VLT is a registered Danfoss trademark
121
