18
Basic Statistics
Electrical System Statistics
Wiring Diagram
Dimensions
Wheel Size: 4.0”x13.5”
Body Size: 171x82x170cm
Seat Height 75cm (29”)
Weight
210 kg without battery
222 kg with battery
Loading Capacity
Standard: 150 kg
Maximum: 205 kg
Speed and Mileage
Max. Speed: 15 km/h
Max. Mileage: 40 km
Motor Statistics
Rated Power: 1200W
Max. Climbing Angle: 12 degrees
Charger Statistics
Charger type: 24V-5AH
Charger Input: AC 100 – 240V
Standard Input voltage: 110V
+/- 10%
Power Rated: 80W
Voltage Charge: 43.2 – 44.2V
Charge Current: 2.5A +/- 0.02A
Charge Time: 4-5 hours
Battery Statistics
Type: Sealed Lead Acid
Voltage: 24V110AH
Battery Life: 300 charges
