6
PRODUCT DESCRIPTION
Electrically-assied bike technical features
A
Rear LED light
B
Battery and controller
C
Beam + connectors: brakes / control screen
D
Control screen
E
Braking detector
F
Front LED light
G
Motor wiring harness
H
Motor
I
Pedalling detector
General operation of the electrical assiance
The electrically-assied bike can be used with or without assiance by pressing the ON/OFF button. Always
lock the battery with the key when in use. The electrical assiance will only operate if you pedal. The assis-
tance will switch o the moment either of the two brake levers is depressed or the speed reaches more than
25 km/h. It will then reart automatically when below 23 km/h. In order to preserve battery life, the bike is
equipped with a «power» limiter that limits assiance when the motor is under heavy rain. During intensive
use and in exceptional weather conditions, the assiance may switch o to safeguard the entire syem.
A
B
C
D
E
F
G
H
I
