Dell 1907FPc Service Manual

Dell 1907FPc
52
Remove the main frame :
Remove the 4 screws (left and
right) by manual or torque =
3kgF.Cm
Samsung panel:
The CCFL line can’t overtop
dashed
LG panel:
The angle between CCFL line
and vertical direction should be
about 30 degree.
Cable hook
Cable hook
