Dell 1907FPc Service Manual

Dell 1907FPc
6
1. Monitor Specifications
LCD Panel
Screen type
Active matrix - TFT LCD
Panel Type
LTM190EX-L01 (LPL)
LM190E03-TLB4 (SEC)
Size 480mm(19.0")
Display Area 376.32(H) x 301.056(V)
Pixel pitch 0.294mm(H) x 0.294mm(V)
Viewable angle (CR>=10)
150(H) / 135(V) (type) (For LTM190EX-L01 panel)
140(H) / 140(V) (type) (For LM190E03-TLB4 panel)
Response time 8ms(type)
Input
Video R, G, B Analog Interface
Separate Sync H/V TTL
H-Frequency 30kHz – 81kHz
V-Frequency 56 - 76Hz
Display Colors 16.7M Colors
Dot Clock 165MHz (Max)
Optimal preset resolution 1280 x 1024 at 60 Hz
Highest preset resolution 1280 x 1024 at 75 Hz
Plug & Play VESA DDC
EPA ENERGY
STAR
®
ON Mode (with Dell
Sound bar and USB
active)
<65W
OFF Mode <3W
Connector Type 15-pin D-subminiature, blue connector; DVI-D, white connector
Input Video Signal
Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input
impedance
Power Source
100 V ~ 240 V± 10 %VAC, 50 ± 3Hz, 60 ± 3Hz
Environmental
Considerations
Temperature:
Operating: 5° to 35°C (41° to 95°F)
Non-operating: Storage: -20° to 60°C (-4° to 140°F); Shipping:
-20° to 60°C (-4° to 140°F)
Humidity:
Operating: 10% to 80%
Non-operating: Storage: 5% to 90%; Shipping: 5% to 90%
Altitude:
Operating: 3,657.6m (12,000 ft) max
Non*operating: 12,192 m (40,000 ft) max
Weight
Weight with packaging: 8.6 kg (18.96 lbs)
Weight with stand assembly and cables: 7.1 kg (15.6 lbs)
Weight without stand assembly: 5.0 kg (11.02 lbs)
Weight of stand assembly: 1.6 kg (3.53 lbs)
