Dell 2009W User Manual

Removing the Stand
Complete the following steps to remove the stand:
1. Rotate the stand to allow access to the stand release button.
2. Press and hold the Stand release button.
3. Lift the stand up and away from the monitor .
Back to Contents Page
NOTICE: DonotusewithanydeviceotherthantheDellSoundbar.
NOTE:Soundbar Power Connector +12V DC output is for optional Dell Soundbar only.
1.
Working from the rear of the monitor, attach the Dell Soundbar by aligning the two slots with the two tabs along the bottom rear of the monitor.
2.
Slide the Dell Soundbar to the left until it snaps into place.
3.
Connect the Dell Soundbar with the DC power connector.
4.
Insert the mini stereo plug from the rear of the Dell Soundbar into the computer's audio output jack.
NOTE: To prevent scratches on the LCD screen while removing the stand,ensure that the monitor is placed on a clean surface.
