Dell Chromebook 3100 Technical Guidebook

Display
Table 17. Display specifications
Feature Specifications
Type 11.6 inch, HD TN Non-Touchscreen, and 187 Nits.
11.6 inch, HD TN Touchscreen, and 187 Nits (optional).
Height (Active area)
144.00 mm
Width (Active area)
256.125 mm
Diagonal
293.83 mm (11.6 inches)
Megapixels
1.04
Pixels Per Inch (PPI)
135
Contrast ratio (Typical)
500:1
Refresh rate
60 Hz
Horizontal viewing angle (min)
+40/-40 degrees
Vertical viewing angle (min)
+10/-30 degrees
Power consumption (max)
3.0 W
GPU-integrated
Table 18. GPU-integrated specifications
Controller Type CPU
Dependency
Graphics
memory type
Capacity External display
support
Maximum
resolution
Intel UHD
Graphics 600
UMA Intel Celeron
N4000 Dual
core CPU
Integrated Shared system
memory
Supported via USB
Type-C port
3840 x 2160 @60
Hz
Operating and storage environment
Table 19. Operating and storage environment
Operating Storage
Temperature range
0°C to 35°C (32°F to 95°F) -40°C to 65°C (-40°F to 149°F)
Relative humidity (maximum)
10% to 90% (noncondensing)
NOTE: Maximum dew point
temperature = 26°C
0% to 95% (noncondensing)
NOTE: Maximum dew point
temperature = 33°C
Vibration (maximum)
2 to 600 Hz at 0.66 Grms 2 to 600 Hz at 1.33 Grms
Shock (maximum)
160 G with pulse duration of 2 ms
(equivalent to 80 in/sec)
160 G with pulse duration of 2 ms
(equivalent to 80 in/sec)
16 Technical specifications

Dell Chromebook 3100 Specifications

General

RAM	4GB LPDDR4
Storage	16GB/32GB eMMC
Display	11.6-inch HD (1366 x 768) Anti-Glare
Operating System	Chrome OS
Battery Life	Up to 14 hours
Wireless	802.11ac Wi-Fi, Bluetooth 5.0
Graphics	Intel UHD Graphics 600
Processor	Intel Celeron N4000
Ports	2 x USB 3.1, 1 x MicroSD card reader, 1 x headphone/microphone combo jack
Battery	42 Whr, 3-cell Li-ion
