Table 16. Power adapter specifications
Feature Specifications
9 V/3 A (continuous)
5 V/3 A (continuous)
Rated output voltage
20 VDC / 15 VDC / 9 VDC / 5 VDC
Temperature range (Operating)
0°C to 40° C (32°F to 104°F)
Temperature range (Non-Operating)
-40°C to 70°C (-40°F to 158°F)
Battery
Table 17. Battery
Feature Specifications
Type 3-cell lithium-ion (42 WHr) 3-cell Polymer (42 WHr)
Dimension Width
Depth
Height
89.15 mm (3.50 inches)
175.47 mm (6.90 inches)
5.90 mm (0.23 inches)
Width
Depth
Height
89.15 mm (3.50 inches)
175.47 mm (6.90 inches)
5.90 mm (0.23 inches)
Weight
(maximum)
0.185 kg (0.40 lb) 0.195 kg (0.42 lb)
Voltage 11.40 VDC 11.40 VDC
Life span 1 year 1 year
Operating time Varies depending on operating conditions and
can significantly reduce under certain power-
intensive conditions
Varies depending on operating conditions and can
significantly reduce under certain power-intensive
conditions
Temperature
range: Operating
● 0°C to 35°C (32°F to 95°F)
● Charge : 0 °C to 50 °C (32 °F to 122 °F)
● Discharge: 0 °C to 70 °C (32 °F to 158 °F)
● 0°C to 35°C (32°F to 95°F)
● Charge : 0 °C to 50 °C (32 °F to 122 °F)
● Discharge: 0 °C to 70 °C (32 °F to 158 °F)
Temperature
range: Storage
- 20 °C to 65 °C (- 4 °F to 149 °F) - 20 °C to 65 °C (- 4 °F to 149 °F)
Display
Table 18. Display specifications
Feature Specifications
Type 11.6 inch, HD TN Non-Touchscreen, and 187 Nits.
11.6 inch, HD TN Touchscreen, and 187 Nits (optional).
Height (Active area)
144.00 mm
Width (Active area)
256.125 mm
Diagonal
293.83 mm (11.6 inches)
Technical specifications 17
