Dell E157FP User Manual

Electrical
Video input signals
Analog RGB, 0.7 Volts +/-5%, 75 ohm input impedance
Synchronization input signals
Separate horizontal and vertical;
3.3V CMOS or 5V TTL level, positive or negative sync.
AC input voltage / frequency / current
100~240 VAC/ 50-60 Hz
1.5A (RMS) max
Inrush current at 120 V
30 A max
Inrush current at 240 V
60 A max
Physical Characteristics
Connector type
15-pin D-subminiature, blue connector
Signal cable type
Detachable, D-sub, 15pin, attached to the monitor
Dimensions: (with stand)

Height
13.29 inches (337.28mm )
Width
13.41 inches (340.29mm )
Depth
5.22 inches (132.58mm)
Dimensions: (without stand)

Height
10.41 inches (264.26mm )
Width
13.41 inches (340.26mm )
Depth
2.32 inches (59mm )
Stand dimensions:

Height
10.84 inches (275.15mm )
Width
10.12 inches (256.89mm )
Depth
5.22 inches (132.58mm )
Weight with packaging
11.2 lb (5.1 kg ) max
Weight with stand assembly and video cable
8.1 lb (3.67 kg ) max
Weight without stand assembly
(For wall mount or VESA mount considerations)
5.40 lb (2.45 kg ) max
Weight of stand assembly
2.3 lb (1.04kg ) max
Environmental
Temperature:

Operating
41°to95°F(5°to35°C)
Nonoperating
-4°to140°F(-20°to60°C)
Humidity:

Operating
10% to 80% (noncondensing)
Nonoperating
5% to 90% (noncondensing)
Altitude:

Operating
3,658 m (12,000 ft)
