Dell E177FP User Manual

Monitor Specifications
General
Model number
E177FP
Flat Panel
Screen type
Active matrix - TFT LCD
Screen dimensions
17 inches (17-inch diagonal viewable image size)
Preset display area:
Horizontal
337.9 mm (13.3 inches)
Vertical
270.3 mm (10.6 inches)
Pixel pitch
0.264 mm x 0.264 mm
Viewing angle
Viewingangle120°(vertical)typ,140°(horizontal)typ
Luminance output
300 cd/m ²(typ)
Contrast ratio
500:1 (typ)
Faceplate coating
Anti-glare with hard-coating 3H
Backlight
4 CCFLs backlight
Response Time
8 ms typical (Black to White)
Resolution
Horizontal scan range
30 kHz to 81 kHz (automatic)
Vertical scan range
56 Hz to 76 Hz
Optimal preset resolution
1280 x 1024 at 60 Hz
Highest preset resolution
1280 x 1024 at 75 Hz

Preset Display Modes
The following table lists the preset modes for which Dell guarantees image size and centering:
Display Mode
Horizontal Frequency
(kHz)
Vertical Frequency (Hz)
Pixel Clock (MHz)
Sync Polarity (Horizontal/Vertical)
VGA, 720 x 400
31.5
70.1
28.3
-/+
VGA, 640 x 480
31.5
60.0
25.2
-/-
VESA, 640 x 480
37.5
75.0
31.5
-/-
VESA, 800 x 600
37.9
60.3
40.0
+/+
VESA, 800 x 600
46.9
75.0
49.5
+/+
VESA, 1024 x 768
48.4
60.0
65.0
-/-
VESA, 1024 x 768
60.0
75.0
78.8
+/+
VESA, 1152 x 864
67.5
75.0
108.0
+/+
VESA, 1280 x 1024
64.0
60.0
108.0
+/+
VESA, 1280 x 1024
80.0
75.0
135.0
+/+
Electrical
Video input signals
Analog RGB: 0.7 Volts +/-5%,75ohminputimpedance
Synchronization input signals
separate horizontal and vertical,
3.3V Cmos or 5V TTL level, positive or negative sync.
AC input voltage / frequency / current
100 to 240 VAC / 50-60 Hz / 1.5A (RMS) Max.
Inrush current
110V: 30A (Max.)
220V: 60A (Max.)
Physical Characteristics
Signal cable type
D-sub: Detachable, Analog, 15pin, blue connector, attached to the monitor
