Back to Contents Page

Setting Up Your Monitor
Dell™E170S/E190SFlatPanelMonitor
Important instructions to set the display resolution to 1280x1024 (Maximum)
For optimal display performance while using the Microsoft Windows®operating systems, set the display resolution to 1280x1024 pixels by performing the
following steps:
1. Right-click on the desktop and click Properties.
2. Select the Settings tab.
3. Move the slider-bar to the right by pressing and holding the left-mouse button and adjust the screen resolution to 1280x1024.
4. Click OK.
Ifyoudonotsee1280x1024 as an option, you may need to update your graphics driver. Please choose the scenario below that best describes the
computer system you are using, and follow the provided directions:
1: If you have a Dell™ desktop or a Dell™ portable computer with internet access.
2: If you have a non Dell™ desktop, portable computer, or graphics card.

Back to Contents Page

Dell E190S Specifications

General

Screen Size	19 inches
Resolution	1280 x 1024
Aspect Ratio	5:4
Panel Type	TN
Brightness	250 cd/m²
Contrast Ratio	800:1
Response Time	5 ms
Connectivity	VGA
Display Type	LCD
Horizontal Viewing Angle	160 degrees
Vertical Viewing Angle	160 degrees
Power Consumption	20W (typical)
