Dell E2209Wc User Manual

22" LCD Color Monitor Dell E2209Wc
5
1. Monitor Specifications
Screen type Active matrix - TFT LCD
Panel Type
LM220WE1-TLE1 KR LGD
Size
22 inches (22-inch viewable image size)
Pixel pitch
0.282 mm (H) x 0.282mm(V)
Viewable angle
160° (vertical) typ, 170° (horizontal) typ
LCD Panel
Response time 5ms typical
Video R, G, B Analog Interface, DVI digital Interface
Separate Sync H/V TTL
H-Frequency 30kHz – 83kHz
Input
V-Frequency 56 - 75Hz
Dynamic contrast ratio 1000:1 (typical)
Luminance output 300 CD/m ²(typical)
Max. Resolution
1680 x 1050 at 60 Hz
Plug & Play VESA DDC
ON Mode <85W
EPA ENERGY
STAR
®
OFF Mode <2W
Input Connector
15-pin D-subminiature, blue connector;
DVI-D, white connector
Preset display area:
Height : 406.7 mm (16.01 inches)
Width: 511.75 mm (20.14 inches)
Depth：163.9 mm（6.4 inches）
Power Source
100 to 240 VAC / 50 or 60 Hz +
3 Hz / 1.5A
Video display capabilities (DVI playback) 480i/480p/576i/576p/720p/1080i/1080p (Support HDCP)
Environmental
Considerations
Operating Temp: 5° to 35°C
Operating Humidity: 10% to 80%
Storage Temp.: -20° to 60°C
Weight
Weight with packaging: 16.70 lbs (7.59 kg)
Weight with stand assembly and cables: 12.91 lbs (5.86 kg)
Weight without stand assembly: 9.25 lbs (4.20 kg)
Weight of stand assembly: 2.73 lbs (1.24 kg)
