Dell EMC PowerEdge R6515 User Manual

System BIOS
To view the System BIOS screen, power on the system, press F2, and click System Setup Main Menu > System BIOS.
Table 2. System BIOS details
Option Description
System Information Provides information about the system such as the system model name, BIOS
version, and Service Tag.
Memory Settings Specifies information and options related to the installed memory.
Processor Settings Specifies information and options related to the processor such as speed and
cache size.
SATA Settings Specifies options to enable or disable the integrated SATA controller and ports.
NVMe Settings Specifies options to change the NVMe settings. If the system contains the
NVMe drives that you want to configure in a RAID array, you must set both
this field and the Embedded SATA field on the SATA Settings menu to
RAID mode. You might also need to change the Boot Mode setting to UEFI.
Otherwise, you should set this field to Non-RAID mode.
Boot Settings Specifies options to specify the Boot mode (BIOS or UEFI). Enables you to
modify UEFI and BIOS boot settings.
Network Settings Specifies options to manage the UEFI network settings and boot protocols.
Legacy network settings are managed
from the Device Settings menu.
NOTE: Network Settings are not supported in BIOS boot mode.
Integrated Devices Specifies options to manage integrated device controllers and ports, specifies
related features, and options.
Serial Communication Specifies options to manage the serial ports, its related features, and options.
System Profile Settings Specifies options to change the processor power management settings, memory
frequency.
System Security Specifies options to configure the system security settings, such as system
password, setup password, Trusted Platform Module (TPM) security, and UEFI
secure boot. It also manages the power button on the system
Redundant OS Control Sets the redundant OS information for redundant OS control.
Miscellaneous Settings Specifies options to change the system date and time.
System Information
To view the System Information screen, power on the system, press F2, and click System Setup Main Menu > System
BIOS > System Information.
Table 3. System Information details
Option Description
System Model Name Specifies the system model name.
System BIOS Version Specifies the BIOS version installed on the system.
System Service Tag Specifies the system Service Tag.
System Manufacturer Specifies the name of the system manufacturer.
System Manufacturer Contact Information Specifies the contact information of the system manufacturer.
Pre-operating system management applications 5

Dell EMC PowerEdge R6515 Specifications

General

Processor cache	32 MB
Processor cores	8
Processor model	7232P
Processor family	AMD EPYC
Processor threads	16
Processor frequency	3.1 GHz
Processor manufacturer	AMD
Processor boost frequency	3.2 GHz
Number of processors installed	1
Memory slots	16x DIMM
Memory ranking	2
Internal memory	16 GB
Buffered memory type	Registered (buffered)
Internal memory type	DDR4-SDRAM
Maximum internal memory	128 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	Serial ATA III
Hot-Plug support	Yes
Optical drive type	No
Supported HDD sizes	2.5, 3.5 \
Total storage capacity	2000 GB
Maximum storage capacity	- TB
Number of HDDs supported	4
Supported RAID controllers	PERC H330
Chassis type	Rack (1U)
Product color	Black
Compatible operating systems	- Canonical Ubuntu Server LTS - Citrix Hypervisor - Microsoft Windows Server with Hyper-V - Red Hat Enterprise Linux - SUSE Linux Enterprise Server - VMware ESXi
Power supply	550 W
Power cable connector 1	C13 coupler
Power cable connector 2	C14 coupler
Power supply input frequency	50 - 60 Hz
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 80 %
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	-
On-board graphics card model	Not available

Weight and Dimensions

Depth	- mm
Width	482 mm
Height	42.8 mm
