Dell G7 7790 User Manual

Replacing the graphics-card fan
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
1. Place the fan at an angle, on the system board and connect the fan cable to the system board.
2. Align the screw holes to the holes on the system board.
3. Replace the three screws (M2x2.5) that secure the fan to the system board.
25
56 Replacing the graphics-card fan

Dell G7 7790 Specifications

General

Graphics	NVIDIA GeForce RTX 2060
Operating System	Windows 10 Home
Processor	Intel Core i7-9750H
Display	17.3-inch FHD (1920 x 1080)
RAM	16GB DDR4
Storage	512GB SSD
Battery	60Whr
Ports	Thunderbolt 3, 3x USB 3.1, HDMI 2.0, RJ-45, Headphone/Mic
