Dell Inspiron 7548 User Manual

WARNING: Before working inside your computer, read the safety
information that shipped with your computer. For more safety best
practices, see the Regulatory Compliance home page at dell.com/
regulatory_compliance.
WARNING: Disconnect all power sources before opening the
computer cover or panels. After you finish working inside the
computer, replace all covers, panels, and screws before connecting to
the power source.
CAUTION: To avoid damaging the computer, make sure that the work
surface is flat and clean.
CAUTION: To avoid damaging the components and cards, handle
them by their edges and avoid touching pins and contacts.
CAUTION: You should only perform troubleshooting and repairs as
authorized or directed by the Dell technical assistance team. Damage
due to servicing that is not authorized by Dell is not covered by your
warranty. See the safety instructions that shipped with the product or
at dell.com/regulatory_compliance.
CAUTION: Before touching anything inside your computer, ground
yourself by touching an unpainted metal surface, such as the metal at
the back of the computer. While you work, periodically touch an
unpainted metal surface to dissipate static electricity, which could
harm internal components.
CAUTION: When you disconnect a cable, pull on its connector or on
its pull-tab, not on the cable itself. Some cables have connectors with
locking tabs or thumb-screws that you must disengage before
disconnecting the cable. When disconnecting cables, keep them
evenly aligned to avoid bending any connector pins. When connecting
cables, make sure that the ports and connectors are correctly oriented
and aligned.
CAUTION: To disconnect a network cable, first unplug the cable from
your computer and then unplug the cable from the network device.
CAUTION: Press and eject any installed card from the media-card
reader.
Recommended Tools
The procedures in this document may require the following tools:
8

Dell Inspiron 7548 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Bus type	DMI2
Stepping	F0
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-5500 Mobile Series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Broadwell
Processor frequency	2.4 GHz
Processor cache type	L3
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.6 GHz
Maximum number of PCI Express lanes	12
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	2 x 8 GB
AC adapter included	Yes
Intel segment tagging	Home office
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
HDD size	2.5 \
HDD speed	5400 RPM
HDD interface	SATA III
Storage media	HDD
Total storage capacity	1000 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Pixel pitch	0.0897 x 0.0897 mm
Display diagonal	15.6 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Native aspect ratio	16:9
Contrast ratio (typical)	400:1
On-board graphics card ID	0x1616
Discrete graphics card model	AMD Radeon R7 M270
On-board graphics card model	Intel® HD Graphics 5500
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	11.2
On-board graphics card dynamic frequency (max)	950 MHz
Audio system	MaxxAudio Pro
Speaker power	2 W
Speakers manufacturer	Waves
Front camera resolution	1280 x 720 pixels
Front camera resolution (numeric)	0.92 MP
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
HDMI version	1.4a
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Pointing device	Touchpad
Keyboard language	US English
Bundled software	McAfee LiveSafe 1YR
Operating system installed	Windows 8.1 Pro
Operating system architecture	64-bit
Processor code	SR23W
Processor ARK ID	85214
Processor package size	40 x 24 x 1.3 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Battery voltage	7.4 V
Battery capacity	58 Wh
Battery life (max)	- h
Battery recharge time	4 h
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.34 A
AC adapter output voltage	19.5 V
Cable lock slot type	Noble
Operating shock	110 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.30 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	261.2 mm
Width	377.8 mm
Height	19.9 mm
Weight	2200 g
