Dell Latitude E4310 User Manual

Back to Contents Page
Specifications
Dell Latitude E4310 Service Manual
System Information
Memory
Audio
Ports and Connectors
Contactless Smart Card (optional)
Display
Touchpad
AC Adapter
Environmental
Processor
Video
Communications
ExpressCards
Fingerprint Reader (Optional)
Keyboard
Battery
Physical
NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start ®Help and Support and select the
option to view information about your computer.
SystemInformation
Chipset
Mobile Intel QS57 Express chipset
Data bus width
64 bits
DRAM bus width
64 bits
Flash EPROM
two SPI chips: one 32 Mbits and one 64 Mbits
PCI bus
32 bits
Processor
Types
Intel Core i3 series
Intel Core i5 series
Intel Core i7 series
L1 cache
32 KB instruction and 32 KB data per core
L2 cache
256 KB
L3 cache
up to 4 MB
External bus frequency
1066 MHz
Memory
Type
DDR3
Speed
1066 MHz
Connectors
two SODIMM sockets
Module capacities
1 GB, 2 GB, or 4 GB
Minimum memory
1 GB
Maximum memory
8 GB
NOTE: Only 64-bit operating systems support more
than 4 GB memory.
Video
Type
integrated on system board
Controller
Intel HD graphics
Output
15-pin VGA connector
Audio
Type
two-channel high definition audio
Controller
IDT 92HD81
Speakers
two
Internal speaker amplifier
1 W per channel
Volume controls
volume up, volume down, and mute buttons
Communications
Network adapter
Intel 10/100/1000 Ethernet LAN on system board
Wireless
l WLAN half mini card
l WLAN/WiMAX half mini card
l WWAN full mini card
l Bluetooth card
l Ultra-wide band (UWB) card

Dell Latitude E4310 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-520M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QS57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	2 x 2 GB
Discrete graphics card model	-
Maximum graphics card memory	- GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Type	PC
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
AC adapter power	65 W
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cable lock slot type	Kensington
Product color	Black
Sustainability certificates	ENERGY STAR
Pointing device	Touchpad
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	215 mm
Width	323 mm
Weight	1540 g
Height (rear)	30.6 mm
Height (front)	26.5 mm
