Display Panel, Brackets, and Hinges
Dell™Latitude™E5410DiscreteServiceManual
Removing the Display Panel, Brackets, and Hinges
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery from the computer.
3. Remove the access panel from the computer.
4. Remove the WLAN card from the computer.
5. Remove the LED cover from the computer.
6. Remove the keyboard from the computer.
7. Remove the display assembly from the computer.
8. Remove the display bezel from the display assembly.
9. Release the display board from its latches.
10. Remove the screws securing the display panel, brackets, and hinges to the display assembly.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.

Dell Latitude E5410 Specifications

General

RAM	Up to 8GB DDR3
Graphics	Intel HD Graphics
Operating System	Windows 7 Professional
Chipset	Intel QM57 Express
Processor	Intel Core i5
Storage	Up to 500GB HDD
Display	14.1-inch (1280x800 or 1366x768)
Battery	6-cell Lithium Ion
Optical Drive	DVD+/-RW
Wireless	Wi-Fi 802.11a/g/n, Bluetooth
Ports	4 x USB 2.0, VGA, Ethernet, eSATA/USB combo, headphone/microphone jack
Dimensions	13.3 inches
