Replacing the speakers
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Using the alignment posts on the palm-rest assembly, place the speakers on the palm-rest assembly.
2 Route the speaker cable through the routing guides on the palm-rest assembly.
3 Adhere the tapes that secure the speaker cable to the touchpad bracket.
4 Connect the speaker cable to the system board.
5 Adhere the tape that secures the speaker cable to the connector.
Post-requisites
1 Replace the battery.
2 Replace the base cover.
25
42 Replacing the speakers
