Table 45. 256 GB SSD, self-encrypting drive specifications (continued)
Environmental operating conditions (non-condensing)
Temperature range 0°C to 70°C
Relative humidity range 10% to 90%
Op shock 1500G
Environmental non-operating conditions (non-condensing)
Temperature range -40°C to 70°C
Relative humidity range 5% to 95%
M.2 2280, 512 GB, PCIe NVMe Gen4 x4, Opal Self-Encrypting Class
40 Solid-State Drive
The following table lists the M.2 2280, 512 GB SSD, self-encrypting drive specifications.
Table 46. 512 GB SSD, self-encrypting drive specifications
Capacity 512 GB
Height (approximate) 2.38 mm (0.09 in.)
Width (approximate) 22.00 mm (0.87 in.)
Depth (approximate) 80.00 mm (3.15 in.)
Interface type PCIe Gen4
Speed (maximum) 64 Gb/s (up to 4 lanes)
MTBF 1.4M hours
Logical blocks 1,000,215,216
Power source
Power consumption (reference only)
● I
dle: 5 mW (PS4 - L12)
● Active: 5 W
Environmental operating conditions (non-condensing)
Temperature range 0°C to 70°C
Relative humidity range 10% to 90%
Op shock 1500G
Environmental non-operating conditions (non-condensing)
Temperature range -40°C to 70°C
Relative humidity range 5% to 95%
Media-card reader
The following table lists the media-card reader specifications of your Precision 3470.
Table 47. Media-card reader (standard offering)
Media supported (Maximum capacity supported will vary by Flash Media Types)
Media Supported
SDXC, SDHC, Micro-SD
S
ecure Digital (SD) 4.0 UHS-II
36 Engineering specifications
