System information

Table 26. System Conguration

Option Description

Integrated NIC Allows you to congure the on-board LAN controller.

• Disabled = The internal LAN is o and not visible to the operating system.

• Enabled = The internal LAN is enabled.

• Enabled w/PXE = The internal LAN is enabled (with PXE boot) (selected by default)

SATA Operation Allows you to congure the operating mode of the integrated hard drive controller.

• Disabled = The SATA controllers are hidden

• AHCI = SATA is congured for AHCI mode

• RAID ON = SATA is congured to support RAID mode (selected by default)

Drives Allows you to enable or disable the various drives on-board:

• SATA-0 (enabled by default)

• SATA-1 (enabled by default)

• SATA-2 (enabled by default)

• M.2 PCIe SSD-0 (enabled by default)

Smart Reporting This eld controls whether hard drive errors for integrated drives are reported during system startup.

The Enable Smart Reporting option is disabled by default.

USB Conguration Allows you to enable or disable the integrated USB controller for:

• Enable USB Boot Support

• Enable External USB Port

All the options are enabled by default.

Audio Allows you to enable or disable the integrated audio controller. The option Enable Audio is selected by

default.

• Enable Microphone

• Enable Internal Speaker

Both the options are selected by default.

Miscellaneous Devices

Allows you to enable or disable the following devices:

• Enable Camera (enabled by default)

Video

Option

Description

LCD Brightness Allows you to set the display brightness depending up on the power source—On Battery and On AC. The LCD

brightness is independent for battery and AC adapter. It can be set using the slider.

NOTE: The video setting is visible only when a video card is installed into the system.

24 System setup
