Dell PowerConnect W-AP92 Specifications

Learn more at Dell.com/PowerConnect-W-Series
SS710_Dell_PowerConnect_W_AP92_93_100110_062011
Specifications
Operating modes
• Multiservice concurrent 802.11a/n or b/g/n WLAN
• Can be configured to operate individually or simultaneously as:
- 802.11a/b/g/n access point
- Air monitor
- Remote AP
- Secure enterprise mesh
• Backward compatible with 802.11a/b/g and mixed-mode
11a/b/g/n deployments
Radios
• Multifunction, single radio capable of 2.4-GHz or 5-GHz operation
• 802.11n radio implements 2x2 MIMO with 2 spatial streams,
providing up to 300 Mbps data rate
• Maximal ratio combining (MRC) for improved receiver performance
Wireless radio specifications
• AP type: Single radio, dual-band 802.11n indoor
• Supported frequency bands (country-specific restrictions apply):
- 2.400 to 2.4835 GHz
- 5.150 to 5.250 GHz with Dynamic Frequency Support
(DFS) Capability
- 5.250 to 5.350 GHz with Dynamic Frequency Support
(DFS) Capability
- 5.470 to 5.725 GHz with Dynamic Frequency Support
(DFS) Capability
- 5.725 to 5.850 GHz with Dynamic Frequency Support
(DFS) Capability
• Available channels: Controller-managed, dependent upon
configured regulatory domain
• Transmit power:
- 2.4 GHz: Up to 23 dBm (limited by local regulatory requirements)
- 5 GHz: Up to 23 dBm (limited by local regulatory requirements)
- Transmit power configurable in increments of 0.5 dBm
• Supported radio technologies:
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n: Orthogonal frequency division multiplexing (OFDM)
- 802.11n: 2x2 MIMO with 2 spatial streams
• Supported modulation types:
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
• Association rates (Mbps):
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n: MCS0 - MCS15 (6.5 Mbps to 300 Mbps)
- 802.11n high-throughput (HT) support: HT 20/40
- 802.11n packet aggregation: A-MPDU, A-MSDU
Antenna
• W-AP92: dual, RP-SMA interfaces for external antenna support
• W-AP93: two integrated, omni-directional antennas
(supporting up to 2x2 MIMO with spatial diversity)
- 2.4 GHz/2.5 dBi
- 5 GHz/5.8 dBi
Interfaces
• 1 x 10/100/1000BASE-T Ethernet (RJ-45), auto-sensing, MDI/MDX
• 1 x RJ-45 serial console interface
Power options
• Ethernet IEEE 802.3af Power over Ethernet (48V DC)
• External AC power providing 12V DC to AP
(adapter sold separately)
• Maximum power consumption: 10 watts
Mounting
• Ceiling tile rail (15/16” & 9/16” recessed or non-recessed)
• Wall mount
Mechanical
• 120 mm x 130 mm x 35 mm (4.7” x 5.1” x 1.4”)
• Weight: 375 g (13.2 oz)
Environmental
• Operating:
- Temp: 0° to 50° C (32° to 122° F)
- Humidity: 5 to 95% non-condensing
• Storage and Transportation:
- Temp: -40° to 70° C (-40° to 158° F)
Certifications
• Wi-Fi certified: 802.11a/b/g/n, Wi-Fi Multimedia (WMM)
• WPA, WPA2, 802.1X
Extended Life Warranty*
Select PowerConnect products carry an Extended
Life Warranty with Basic Hardware Service (repair
or replacement) for as long as you own the
product. *Warranty extends until five years after
end of product model sales. PowerConnect
switches not only provide the quality, reliability and capability
you expect from Dell, but also the protection that comes with an
Extended Life Warranty.
Details at Dell.com/warranty
© 2011 Dell Inc, All Rights Reserved. Dell, the DELL logo, and PowerConnect are trademarks of Dell Inc. Reproduction of these materials in any manner
whatsoever without the written permission of Dell Inc. is strictly forbidden.
© 2011 Aruba Networks, Inc. AirWave
®
, Aruba Networks
®
, Aruba Mobility Management System
®
, and other registered marks are trademarks of Aruba Networks,
Inc. Specifications are subject to change without notice. Originated in the USA. Any other trademarks appearing in this manual are the property of their
respective companies.
*Select PowerConnect products carry an Extended Life Warranty with Basic Hardware Service. Warranty covers repair or replacement of the product for as long
as it remains in use by the customer. In the event of discontinuance of product manufacture, Dell Extended Life Warranty extends until five (5) years after end of
product model sales. Warranty limits fan and power supply to five (5) years from date of purchase. Warranty does not include troubleshooting, configuration, or
other advanced service provided by Dell ProSupport. For more information see dell.com/warranty.

Dell PowerConnect W-AP92 Specifications

Wireless Radio Specifications

supported frequency bands	2.400 to 2.4835 GHz, 5.150 to 5.850 GHz
transmit power 2.4 GHz	up to 23 dBm
transmit power 5 GHz	up to 23 dBm

Interfaces

ethernet interface	1 x 10/100/1000BASE-T Ethernet (RJ-45)
serial console interface	1 x RJ-45
power over ethernet	IEEE 802.3af Power over Ethernet (48V DC)

Power

external AC power	12V DC
maximum power consumption	10 watts
power over ethernet	48V DC

Operating Environment

operating temperature	0° to 50° C
operating humidity	5 to 95% non-condensing
storage temperature	-40° to 70° C

Weight and Dimensions

dimensions	120 mm x 130 mm x 35 mm
weight	375 g
antenna gain 2.4 GHz	2.5 dBi
