Dell SE2722H User Manual

About your monitor │ 13
Monitor specifications
Model SE2722H/SE2722HX
Screen type Active matrix-TFT LCD
Panel type Vertical Alignment
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
684.66 mm ( 27 in.)
596.74 mm (23.49 in.)
335.66 mm (13.22 in)
2003.02 cm
2
(310.54 in.
2
)
Native resolution and
refresh rate
1920 x1080 at 75Hz (HDMI 1.4)
Pixel pitch 0.3108 mm x 0.3108 mm
Pixel per inch (PPI) 81
Viewing angle
Horizontal
Vertical
178° (typical)
178° (typical)
Luminance output 250 cd/m² (typical)
Contrast ratio 3000 to 1 (typical)
Faceplate coating Anti-glare with 3H hardness
Backlight LED edgelight system
Response time (Gray to
Gray）
Normal mode 8ms
Fast mode 5ms
Extreme mode 4ms
NOTE:
The 4 ms gray-to-gray mode is achievable in the
Extreme mode to reduce visible motion blur and
increased image responsiveness. However this may
introduce some slight and noticeable visual artifacts into
the image.
Color depth 16.7 million colors
Color gamut NTSC CIE1976(84%) CIE1931(72%)

Dell SE2722H Specifications

General

Panel type	VA
Pixel pitch	0.3108 x 0.3108 mm
Screen shape	Flat
Pixel density	81 ppi
Response time	8 ms
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Response time (fast)	5 ms
Horizontal scan range	30 - 83 kHz
Viewable size diagonal	684.66 mm
NTSC coverage (typical)	84 %
Viewable size, vertical	335.66 mm
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.47 cm
Viewable size, horizontal	596.74 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
NVIDIA G-SYNC	-
LED indicators	Power
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
HDMI version	1.4
DisplayPorts quantity	0
Product color	Black
Market positioning	Business
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	24 W
Power consumption (off)	0.3 W
Power consumption (typical)	20 W
Package depth	720.09 mm
Package width	447.04 mm
Package height	139.95 mm
Package weight	6370 g
Cables included	AC, HDMI, VGA
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	13.22 mm
Bezel width (side)	13.28 mm
Depth (with stand)	199.87 mm
Width (with stand)	623.3 mm
Height (with stand)	459.21 mm
Weight (with stand)	4400 g
Bezel width (bottom)	16.44 mm
Depth (without stand)	55.56 mm
Height (without stand)	369.61 mm
Weight (without stand)	3800 g
