Dell SE2722HX User Manual

10 | Organizing Windows With Easy Arrange
Organizing Windows With Easy Arrange
On supported Dell monitors, the Easy Arrange tab enables you to easily arrange the
open windows in one of the predefined layouts by dragging them in the zones. Press
“>” or use Page Up/Page Down key to find more layouts. To create a custom layout,
arrange the open windows and then click Save.
To get started with Easy Arrange, choose a target monitor and select one of
the predefined layouts. The regions for that layout are displayed momentarily on
the monitor. Next, drag an open window across the monitor. While the window is
being dragged, the current window layout is displayed and an active region gets
highlighted as the window passes over it. At any time, drop the window into the
active region to place the window in that region.
Dell SE2722H
To create a custom window layout, size and position the windows on the desktop
and then click the Save link in Easy Arrange. The size and position of the windows
is saved as a custom layout and the custom layout icon is created.
NOTE: This option does not save or remember the applications that are
open. Only the size and position of the windows is saved.

Dell SE2722HX Specifications

General

Screen shape	Flat
Pixel density	81 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Response time (fast)	5 ms
Viewable size diagonal	684.66 mm
NTSC coverage (typical)	84 %
Viewable size, vertical	335.66 mm
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.47 cm
Viewable size, horizontal	596.74 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
NVIDIA G-SYNC	-
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
HDMI version	1.4
DisplayPorts quantity	0
Input current	1.6 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	24 W
Power consumption (off)	0.3 W
Power consumption (typical)	20 W
Cables included	AC, HDMI, VGA
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Home
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	13.22 mm
Bezel width (side)	13.28 mm
Depth (with stand)	199.87 mm
Width (with stand)	623.3 mm
Height (with stand)	459.21 mm
Weight (with stand)	4740 g
Bezel width (bottom)	16.44 mm
Depth (without stand)	55.56 mm
Height (without stand)	369.61 mm
Weight (without stand)	3800 g
