Dell SE2722HX User Manual

6 | Using The Quick Settings Dialog
NOTE:
Feature Function Description
Quick DDM Access Quick key to call up
DDM UI.
Ctrl+Shift+D
Use page up/down key or click on “>”
to flip through all Easy Arrange layouts.
Control individual
monitor in multi-
monitor setup
From dropdown box to select monitor,
selected monitor has Dell logo shown.
Move DDM UI to the monitor to be
controlled.
Press Ctrl+Shift+D to bring up the mini
UI under the mouse pointer.

Dell SE2722HX Specifications

General

Screen shape	Flat
Pixel density	81 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Response time (fast)	5 ms
Viewable size diagonal	684.66 mm
NTSC coverage (typical)	84 %
Viewable size, vertical	335.66 mm
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	68.47 cm
Viewable size, horizontal	596.74 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
NVIDIA G-SYNC	-
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
HDMI version	1.4
DisplayPorts quantity	0
Input current	1.6 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	24 W
Power consumption (off)	0.3 W
Power consumption (typical)	20 W
Cables included	AC, HDMI, VGA
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Home
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	13.22 mm
Bezel width (side)	13.28 mm
Depth (with stand)	199.87 mm
Width (with stand)	623.3 mm
Height (with stand)	459.21 mm
Weight (with stand)	4740 g
Bezel width (bottom)	16.44 mm
Depth (without stand)	55.56 mm
Height (without stand)	369.61 mm
Weight (without stand)	3800 g
